Item # |
List Price |
Module |
No. of teeth |
Direction of Spiral |
Bore (A) |
Pitch Diameter (C) |
CAD |
Add To Cart/Request Quote |
|---|---|---|---|---|---|---|---|---|
| PUH1.5-24L PUH1.5-24L/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 1.5 | No. of teeth N/A 24 | Direction of Spiral N/A Left | Bore (A) N/A 0.472 in12 mm | Pitch Diameter (C) N/A 1.504 in38.2 mm | CAD N/A |
Add To Cart
Request Quote |
| PUH1.5-24R PUH1.5-24R/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 1.5 | No. of teeth N/A 24 | Direction of Spiral N/A Right | Bore (A) N/A 0.472 in12 mm | Pitch Diameter (C) N/A 1.504 in38.2 mm | CAD N/A |
Add To Cart
Request Quote |
| PUH10-17L PUH10-17L/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 10 | No. of teeth N/A 17 | Direction of Spiral N/A Left | Bore (A) N/A 0.787 in20 mm | Pitch Diameter (C) N/A 7.102 in180.4 mm | CAD N/A |
Add To Cart
Request Quote |
| PUH10-17R PUH10-17R/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 10 | No. of teeth N/A 17 | Direction of Spiral N/A Right | Bore (A) N/A 0.787 in20 mm | Pitch Diameter (C) N/A 7.102 in180.4 mm | CAD N/A |
Add To Cart
Request Quote |
| PUH2-17L PUH2-17L/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 2 | No. of teeth N/A 17 | Direction of Spiral N/A Left | Bore (A) N/A 0.472 in12 mm | Pitch Diameter (C) N/A 1.421 in36.1 mm | CAD N/A |
Add To Cart
Request Quote |
| PUH2-17R PUH2-17R/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 2 | No. of teeth N/A 17 | Direction of Spiral N/A Right | Bore (A) N/A 0.472 in12 mm | Pitch Diameter (C) N/A 1.421 in36.1 mm | CAD N/A |
Add To Cart
Request Quote |
| PUH3-17L PUH3-17L/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 3 | No. of teeth N/A 17 | Direction of Spiral N/A Left | Bore (A) N/A 0.472 in12 mm | Pitch Diameter (C) N/A 2.130 in54.1 mm | CAD N/A |
Add To Cart
Request Quote |
| PUH3-17R PUH3-17R/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 3 | No. of teeth N/A 17 | Direction of Spiral N/A Right | Bore (A) N/A 0.472 in12 mm | Pitch Diameter (C) N/A 2.130 in54.1 mm | CAD N/A |
Add To Cart
Request Quote |
| PUH4-17L PUH4-17L/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 4 | No. of teeth N/A 17 | Direction of Spiral N/A Left | Bore (A) N/A 0.472 in12 mm | Pitch Diameter (C) N/A 2.843 in72.2 mm | CAD N/A |
Add To Cart
Request Quote |
| PUH4-17R PUH4-17R/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 4 | No. of teeth N/A 17 | Direction of Spiral N/A Right | Bore (A) N/A 0.472 in12 mm | Pitch Diameter (C) N/A 2.843 in72.2 mm | CAD N/A |
Add To Cart
Request Quote |
| PUH5-17L PUH5-17L/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 5 | No. of teeth N/A 17 | Direction of Spiral N/A Left | Bore (A) N/A 0.787 in20 mm | Pitch Diameter (C) N/A 3.551 in90.2 mm | CAD N/A |
Add To Cart
Request Quote |
| PUH5-17R PUH5-17R/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 5 | No. of teeth N/A 17 | Direction of Spiral N/A Right | Bore (A) N/A 0.787 in20 mm | Pitch Diameter (C) N/A 3.551 in90.2 mm | CAD N/A |
Add To Cart
Request Quote |
| PUH6-17L PUH6-17L/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 6 | No. of teeth N/A 17 | Direction of Spiral N/A Left | Bore (A) N/A 0.787 in20 mm | Pitch Diameter (C) N/A 4.260 in108.2 mm | CAD N/A |
Add To Cart
Request Quote |
| PUH6-17R PUH6-17R/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 6 | No. of teeth N/A 17 | Direction of Spiral N/A Right | Bore (A) N/A 0.787 in20 mm | Pitch Diameter (C) N/A 4.260 in108.2 mm | CAD N/A |
Add To Cart
Request Quote |
| PUH8-17L PUH8-17L/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 8 | No. of teeth N/A 17 | Direction of Spiral N/A Left | Bore (A) N/A 0.787 in20 mm | Pitch Diameter (C) N/A 5.681 in144.3 mm | CAD N/A |
Add To Cart
Request Quote |
| PUH8-17R PUH8-17R/ImgCustom/1002/placeholder_notavailable.gif | QUOTE | Module N/A 8 | No. of teeth N/A 17 | Direction of Spiral N/A Right | Bore (A) N/A 0.787 in20 mm | Pitch Diameter (C) N/A 5.681 in144.3 mm | CAD N/A |
Add To Cart
Request Quote |
